Home > Stainless Steel > Stainless Steel Condenser Tube
Stainless Steel Condenser Tube are known for exceptional strength and corrosion resistance, ideal for demanding industrial applications such as marine, chemical processing, oil and gas etc. They work reliably in harsh conditions, resist pitting and cracking. As a leading manufacturer and supplier in Dubai, UAE, we offer high quality stainless steel condenser tubes. Our pipe ensures consistent performance and durability while meeting the highest standards for critical applications.
| Grades | 316N, 316, 316L 309S, 310S 316LN, 304N 317, 304LN, 316Ti 304H 347H, 347 304, 321 317L 321H, 304L 310H |
| Manufacturing Type | Fabricated / Seamless / ERW / DOM / Welded / CDW / CDS / CEW / 100% X Ray Welded |
| ASTM Specification | ASTM A213, ASTM A312, ASTM A269 |
| Delivery Condition | Bright Annealed (BA), Annealed and Pickled (AP), Polished, Cold Drawn, MF |
| Processing Service | Decoiling, Bending, Welding, Punching, Cutting, Moulding |
| International Standard |
|
| Technique | Cold rolled, Cold drawn, Hot rolled, Extrusion Tube |
| Grades | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
|---|---|---|---|---|---|---|---|---|
| TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
| TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Grade | Elongation (min. %) | Temperature Range (ºC [ºF]) | Tensile Stress (min. MPa) | Yield Stress (min. MPa) | Hardness (max. Rockwell) |
|---|---|---|---|---|---|
| TP310H | 35 | 590 [1095] | 515 | 205 | 90 HRB |
| TP304H | 35 | 590 [1095] | 515 | 205 | 90 HRB |
| TP321H | 35 | 600 [1110] | 515 | 205 | 90 HRB |
| TP347HFG | 35 | 650 [1200] | 550 | 205 | 90 HRB |
| TP347/347H | 35 | 610 [1130] | 515 | 205 | 90 HRB |
| TP316H | 35 | 610 [1130] | 515 | 205 | 90 HRB |
| TP310HCbN | 30 | 670 [1240] | 655 | 295 | 100 HRB |
| S30432 | 35 | 650 [1200] | 590 | 235 | 95 HRB |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel Condenser Tube as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel Condenser Tube applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, stainless steel condenser tubes can be recycled. Stainless steel is highly recyclable and retains its properties through the recycling process. Ensure proper cleaning to remove any contaminants before recycling.
