Stainless steel coil tubing is known for its exceptional durability and corrosion resistance, making it ideal for harsh industrial environments such as marine, chemical processing and oil and gas fields These coils excel in condition severe conditions, resist pitting and crack corrosion. As a leading manufacturer and dealer in Dubai, UAE, we offer high quality stainless steel coil tubing adhering to the highest standards, ensuring reliable performance and durability for essential services.
| Standard | ASTM A269 /ASME SA 269, ASTM A213/ASME SA213, EN10216-5, JIS G3463 |
| Tolerance | D4/T4 |
| Strength | Tensile, Burst |
| Hardness | Rockwell, Micro |
| Soundness Tests | Eddy Current, Ultrasonic |
| Leak & Strength | Hydrostatic |
| Value Added Services |
|
| Available sizes in stock |
|
| END | Plain End |
| Port | Mumbai, India |
| Types & Their Application |
|
| SS 304/L (UNS S30400/ S30403) | |||||||
|---|---|---|---|---|---|---|---|
| CR | NI | C | MO | MN | SI | PH | S |
| 18.0-20.0 | 8.0-12.0 | 00.030 | 00.0 | 2.00 | 1.00 | 00.045 | 00.30 |
| SS 316/L (UNS S31600/ S31603) | |||||||
| CR | NI | C | MO | MN | SI | PH | S |
| 16.0-18.0 | 10.0-14.0 | 00.030 | 2.0-3.0 | 2.00 | 1.00 | 00.045 | 00.30* |
| Material | Heat | Temperure | Tensile Stress | Yield Stress | Elongation %, Min |
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel Coil Tubing as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel Coil Tubing applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Stainless steel coil tubing is generally suitable for high-temperature applications due to its excellent heat resistance and structural integrity. Grades like 316 or 310 stainless steel offer better performance in extreme temperatures. However, it’s essential to select the appropriate grade based on the specific temperature range and environmental conditions.
