Stainless Steel 410 Forging is known for its versatility and durability in various industrial applications. Known for its high strength, corrosion resistance and heat resistance, SS 410 forged components are essential in the automotive, aerospace and construction industries. These forges excel in environments that require durability and reliability under difficult circumstances. Find precision craftsmanship and customized solutions in stainless steel 410 forging designed to meet exacting standards and performance requirements.
| Type 410 Chemical Composition, % | ||||||||
| ASTM / SAE | AISI (UNS) | C | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni, ≤ |
| ASTM A276/A276M | 410 (UNS S41000) | 0.08-0.15 | 1.00 | 1.00 | 0.040 | 0.030 | 11.5-13.5 | – |
| ASTM A580/A580M | 0.15, ≤ | 1.00 | 1.00 | 0.04 | 0.03 | 11.5-13.5 | – | |
| ASTM A959 | ||||||||
| ASTM A479/A479M | ||||||||
| ASTM A314 | ||||||||
| ASTM A240/A240M | 0.08-0.15 | 1.00 | 1.00 | 0.04 | 0.03 | 11.5-13.5 | 0.75 | |
| ASTM A473 | 0.15, ≤ | |||||||
| SAE J405 | 0.15, ≤ | |||||||
| ASTM A276 Type 410 Mechanical Properties | ||||||
| ASTM | AISI (UNS) | Tensile Strength, Mpa (ksi), ≥ | 0.2% Yield Strength, Mpa (ksi), ≥ | Elongation in 2 in. (50 mm) or 4D, ≥ % | Reduction of area, ≥ % | Condition & finish |
| ASTM A276/A276M | 410 (UNS S41000) | 480 (70) | 275 (40) | 20 | 45 | A, hot-finished |
| 480 (70) | 275 (40) | 16 | 45 | A, cold-finished | ||
| 690 (100) | 550 (80) | 15 | 45 | T, hot-finished | ||
| 690 (100) | 550 (80) | 12 | 45 | T, cold-finished | ||
| 830 (120) | 620 (90) | 12 | 40 | H, hot-finished | ||
| 830 (120) | 620 (90) | 12 | 40 | H, cold-finished | ||
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel 410 Forging as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel 410 Forging applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, Stainless Steel 410 forging is recyclable. Like other stainless steels, SS 410 can be recycled through melting and reprocessing without compromising its mechanical properties. This recyclability makes it an environmentally sustainable choice, reducing the demand for new raw materials and minimizing waste. Recycled stainless steel 410 can be used to manufacture new forgings and other products, contributing to resource conservation and sustainable manufacturing practices in various industries.
