Stainless Steel 347H Forgings are valued for their exceptional resistance to high temperature and corrosion. With excellent mechanical properties, SS 347H forged components are important in aerospace, chemical and thermal environments. Its robust design provides high reliability, making it ideal for applications that require long-term operation at high temperatures. Experienced precision-built stainless steel 347H forging solutions that meet stringent industry standards, ensuring durability and performance in harsh conditions.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
| SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel 347H Forging as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel 347H Forging applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, Stainless Steel 347H forging is recyclable. Like other stainless steels, SS 347H can be recycled through melting and reprocessing without losing its valuable properties. This recyclability supports sustainable practices by conserving resources and reducing environmental impact. Recycled stainless steel 347H can be used to manufacture new forgings and other products, making it an eco-friendly choice for various industrial applications focused on environmental stewardship.
