Stainless Steel 305 Forging is known for its excellent formability and corrosion resistance. Ideal for applications requiring non-magnetic properties and high ductility, SS 305 forged components are essential in the electronics, food processing, and chemical industries. These forgings ensure precision and durability, making them suitable for complex and demanding environments. Experience the reliability and superior performance of Stainless Steel 305 forging, crafted to meet stringent industry standards.
| Element | Content (%) |
|---|---|
| Iron, Fe | 67 |
| Chromium, Cr | 18 |
| Nickel, Ni | 12 |
| Manganese, Mn | ≤ 2 |
| Silicon, Si | ≤ 1 |
| Carbon, C | 0.12 |
| Phosphorous, P | 0.045 |
| Sulfur, S | 0.030 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength, ultimate | 585 MPa | 84800 psi |
| Tensile strength, yield (@0.2%) | 260 MPa | 37700 psi |
| Modulus of elasticity | 193 GPa | 28000 ksi |
| Shear modulus | 86 GPa | 12500 ksi |
| Elongation at break (in 50 mm) | 50 | 50 |
| Hardness, Brinell | 80 | 80 |
| Hardness, Knoop (converted from Brinell hardness) | 97 | 97 |
| Hardness, Rockwell B (converted from Brinell hardness) | 45 | 45 |
| Hardness, Vickers (converted from Brinell hardness) | 82 | 82 |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel 305 Forging as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel 305 Forging applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, Stainless Steel 305 forging is recyclable. Like other stainless steels, SS 305 can be recycled through melting and reprocessing without losing its beneficial properties. This recyclability supports sustainable practices by conserving resources, reducing energy consumption, and minimizing waste. Recycled stainless steel 305 can be used to create new forgings and other products, making it an environmentally friendly choice for various industrial applications focused on sustainability.
