Stainless steel 304 perforated tubes are known for their strength and corrosion resistance, making them perfect for hardsh environments like marine, chemical processing, oil and gas industries etc. They resist pitting and cracking and easily withstand harsh conditions. As the leading company in Dubai, UAE, we offer high quality stainless steel 304 perforated tubes to the highest standards. Our products ensure reliable and durable performance, which is essential for critical cleaning jobs.
Dimenisons :ASTM, AISI, ASME, JIS, DIN, EN, GB, BS, SUS
OD.: 1/8″ NB to 24″ NB, 1/4″ OD to 24″ OD sizes stainless steel welded tubes also available
Thickness : 0.2 mm to 15 mm
Hole size : 3 mm dia on a 6 mm pitch
Material Grade : SS 304
Opening diameter : 0.2 mm to 100 mm
Finish : BA Finish inside and outside, Perforated finish inside and outside
Type : As Welded, EFW, ERW, Seamless, Semi Seamless, Bead Removed
Mill Test Certificate : EN10204 3.1
Packing : Sleeved, Ends Capped, Wooden Boxed
| GRADE | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel 304 Perforated Tubes as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel 304 Perforated Tubes applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, Stainless Steel 304 perforated tubes can be welded. Proper preparation, including cleaning and alignment, is essential to ensure a strong weld. Using the right filler material and welding technique will help achieve a high-quality result.
