Home > Stainless Steel 205 Forging
Stainless Steel 205 Forgings are recognized as strong and corrosion-resistant machines, ideal for long-term applications in harsh environments. They are made primarily by adding manganese to chromium and nickel, an alloy that yields excellent weldability and formability. Stainless Steel 205 is suitable for automotive, aerospace, construction and other applications, where reliability and performance under varying conditions are critical to maintaining system integrity and efficiency.
| Element | Content (%) |
|---|---|
| Iron, Fe | Balance |
| Chromium, Cr | 16.5-18.0 |
| Manganese, Mn | 14.0-15.5 |
| Nickel, Ni | 1.0-1.75 |
| Silicon, Si | 1 |
| Nitrogen, N | 0.32-0.40 |
| Carbon, C | 0.12-0.25 |
| Phosphorous, P | 0.06 |
| Sulfur, S | 0.03 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 790 – 830 MPa | 115000 – 120000 psi |
| Yield strength (@strain 0.200 %) | 450 – 475 MPa | 65300 – 68900 psi |
| Elastic modulus | 197 GPa | 28572 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 40% | 40% |
| Hardness, Rockwell B | 100 | 100 |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Stainless Steel 205 Forging as per DIN, ISO, JIS or ANSI Standard.
Stainless Steel 205 Forging applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, Stainless Steel 205 (Nitronic 50) forging is recyclable. Stainless steels, including Nitronic 50, are highly recyclable materials. The recycling process involves melting down the stainless steel scrap and reusing it to create new products or components. This process can be repeated indefinitely without compromising the material’s properties, making stainless steel 205 forging an environmentally sustainable choice. Recycling stainless steel helps conserve natural resources, reduces energy consumption, and minimizes waste disposal, making it a preferred option in many industries committed to sustainability.
