Home > SA 516 GR.70N NACE MR 0103/0175 Sheet Plates
Discover our SA 516 GR.70N NACE MR 0103/0175 Sheet Plates, crafted to deliver exceptional performance in demanding industrial applications. These plates are designed for superior resistance to hydrogen-induced cracking (HIC) and sulfide stress cracking (SSC), fully adhering to the stringent requirements of NACE MR 0103 and MR 0175 standards. Ideal for use in the oil, gas, and petrochemical industries, they provide outstanding durability, corrosion resistance, and reliability. With a focus on quality and customer satisfaction, we offer tailored solutions, competitive pricing, and timely delivery to meet your specific needs. Elevate your operations with our high-performance plates, engineered for excellence.
| Grade | : | ASME SA 516 GR.70N Boiler and Pressure Vessel Steel Plates |
|---|---|---|
| Width | : | 1000mm-4500mm |
| Thickness | : | 5mm-150mm |
| Length | : | 3000mm-18000mm |
| Supply Condition | : | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | : | 52° C |
| Tempering | : | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | : | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | : | Hot-Rolled (HR) |
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These SA 516 GR.70N NACE MR 0103/0175 Sheet Plates as per DIN, ISO, JIS or ANSI Standard.
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Yield strength (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 485-620 (70-90) | 260 (38) | 17 | 21 |
SA 516 GR.70N NACE MR 0103/0175 Sheet Plates applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, SA 516 GR.70N NACE MR 0103/0175 Sheet Plates are fully recyclable. Made from high-quality carbon steel, these plates can be melted down and reused without losing their inherent material properties. Recycling these plates reduces environmental impact by conserving resources and minimizing waste. This makes them a sustainable choice for industries looking to adopt eco-friendly practices while maintaining the performance and durability needed for demanding applications.
