Home > SA 516 GR.60N NACE + HIC Sheet Plates
Explore our SA 516 GR.60N NACE + HIC Sheet Plates, designed to excel in the most challenging industrial environments. These plates are engineered to offer superior resistance to hydrogen-induced cracking (HIC) and ensure reliable performance in sour service conditions. Compliant with NACE standards, they deliver outstanding durability and corrosion resistance, making them ideal for use in the oil, gas, and petrochemical sectors. Our SA 516 GR.60N plates are crafted to meet the highest quality standards, ensuring long-lasting performance and reliability. With a commitment to customer satisfaction, we provide customized solutions, competitive pricing, and prompt delivery to meet your specific project requirements. Choose our high-performance plates for enhanced operational efficiency and safety.
| Grade | : | ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates |
|---|---|---|
| Width | : | 1000mm-4500mm |
| Thickness | : | 5mm-150mm |
| Length | : | 3000mm-18000mm |
| Supply Condition | : | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | : | 52° C |
| Tempering | : | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | : | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | : | Hot-Rolled (HR) |
| British Standard | European Norm | ASTM/ASME | DIN | |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 |
|
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These SA 516 GR.60N NACE + HIC Sheet Plates as per DIN, ISO, JIS or ANSI Standard.
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
SA 516 GR.60N NACE + HIC Sheet Plates applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, SA 516 GR.60N NACE + HIC Sheet Plates are recyclable. As they are primarily made from carbon steel, they can be melted down and repurposed for various industrial applications, contributing to sustainability efforts. Recycling these plates reduces the demand for new raw materials, conserves energy, and lowers environmental impact. However, the process of recycling should follow industry standards to ensure material integrity and compliance with safety regulations.
