Inconel 600 forgings represent the pinnacle of high-performance alloys, known for exceptional strength, heat resistance, and corrosion resistance. Made primarily of nickel and chromium, with added bulk steel, these forges excel at challenging areas such as chemical processing and aerospace applications. Together, thanks to high thermal stability and reliability, Inconel 600 forgings ensure durability and performance, meeting the exacting requirements of today’s industrial applications den of solutions.
| Specifications | ASTM B564, ASME SB564, AMS 5665 |
|---|---|
| Standard | BS 3072-3076 (NA14) DIN 17742, DIN 17750, DIN 17754 WERKSTOFF Nr 2.4816 TÜV 305 AFNOR-NC 15 Fe, DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These Inconel 600 Forging as per DIN, ISO, JIS or ANSI Standard.
Inconel 600 Forging applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
Yes, Inconel 600 forgings are recyclable. These alloys primarily consist of nickel and chromium, both of which are highly recyclable metals. Recycling Inconel 600 forgings helps conserve resources, reduce waste, and minimize environmental impact. By reclaiming and reusing these materials in various industrial applications, recycling supports sustainable practices in manufacturing and engineering sectors, contributing to efficient resource management and environmental stewardship.
