Home > Other Material > ASTM A193 B8 CL3 Fasteners
Material | Specification | Standards | Size | Length |
ASTM A193 B8 CL3 Fasteners
| IS BS ASTM | DIN, ISO, JIS, GB, IS, BS, ASTM | M 02 to M 160 | 3 mm to 200 mm |
| Grade | Size | Tensile ksi, min | Yield, ksi, min | Elong, %, min | RA % min |
| B8 CL3 | Up to 2-1/2 | 125 | 105 | 16 | 50 |
| 2-5/8 – 4 | 115 | 95 | 16 | 50 | |
| 4-1/8 – 7 | 100 | 75 | 18 | 50 | |
| B8 CL3 Class 1 | All | 75 | 30 | 30 | 50 |
| B8 CL3 Class 1 | All | 75 | 30 | 30 | 50 |
| B8 CL3 Class 2 | Up to 3/4 | 125 | 100 | 12 | 35 |
| 7/8 – 1 | 115 | 80 | 15 | 35 | |
| 1-1/8 – 1-1/4 | 105 | 65 | 20 | 35 | |
| 1-3/8 – 1-1/2 | 100 | 50 | 28 | 45 | |
| B8 CL3 Class 2 | Up to 3/4 | 110 | 95 | 15 | 45 |
| 7/8 – 1 | 100 | 80 | 20 | 45 | |
| 1-1/8 – 1-1/4 | 95 | 65 | 25 | 45 | |
| 1-3/8 – 1-1/2 | 90 | 50 | 30 | 45 |
| Element | B7 | B8 | B8M |
| Carbon | 0.37 – 0.49% | 0.08% max | 0.08% max |
| Manganese | 0.65 – 1.10% | 2.00% max | 2.00% max |
| Phosphorus, max | 0.035% | 0.045% | 0.045% |
| Sulfur, max | 0.040% | 0.030% | 0.030% |
| Silicon | 0.15 – 0.35% | 1.00% max | 1.00% max |
| Chromium | 0.75 – 1.20% | 18.0 – 20.0% | 16.0 – 18.0% |
| Nickel | 8.0 – 11.0% | 10.0 – 14.0% | |
| Molybdenum | 0.15 – 0.25% | 2.00 – 3.00% |
At PipingMart, we take pride in being the largest supplier and manufacturer in the UAE, offering cutting-edge solutions for all your piping needs. With state-of-the-art production plants strategically located in the UAE, we boast a vast inventory of over 25,000 tons of premium-quality materials readily available in stock.
Contact us to get a quick quote for your requirement.
We offer These ASTM A193 B8 CL3 Fasteners as per DIN, ISO, JIS or ANSI Standard.
Corrosion Resistance: ASTM A193 B8 Class 3 fasteners are made from 304 stainless steel, which provides excellent resistance to corrosion in a wide range of environments, including marine and industrial settings. This makes them suitable for use in outdoor or corrosive environments where protection against rust is crucial.
Strength and Durability: These fasteners are manufactured to meet stringent mechanical property requirements, ensuring high tensile strength, good yield strength, and superior durability. They can withstand high stress and load conditions without compromising performance.
Temperature Resistance: They exhibit good resistance to high temperatures, up to certain limits, which makes them suitable for applications where temperature variations are expected without significant degradation in mechanical properties.
Aesthetic Appeal: 304 stainless steel has a bright, clean finish that maintains its appearance over time. This can be advantageous in applications where aesthetics are important, such as architectural or decorative installations.
Wide Application Range: ASTM A193 B8 Class 3 fasteners find application in various industries including construction, automotive, marine, and manufacturing. They are versatile and can be used in diverse settings due to their corrosion resistance and strength characteristics.
ASTM A193 B8 CL3 Fasteners applications are as diverse as the industries they serve driven primarily by the aerospace, railway, construction and automotive industries with petrochemical, nuclear, medical, Oil & Gas, Chemical, Pharmaceutical, Food & Beverage, Nuclear, Thermal Power plants, Paper and Pulp, marine and mining, etc.
